The Pepperl+Fuchs 3RG4031-6JB00-PF is a compact photoelectric sensor designed for diffuse reflection sensing with a range up to 450 mm. It features an NPN output, an M12 connector, and a robust IP67-rated housing for reliable operation in harsh industrial environments.
| Property | Value |
| Product Type | Photoelectric Sensor |
| Operating Principle | Diffuse Reflection |
| Output Type | NPN Normally Open |
| Supply Voltage | 10-30 V DC |
| Connection | 3-pin M12 Connector |
| Housing Material | Polycarbonate (PC) |
| Property | Value |
| Protection Class | IP67 |
| Degree of Contamination | 3 |
| Max. Ambient Illumination | 10,000 Lux (incandescent) |
| Operating Temperature | -25 °C ... +60 °C |
| Storage Temperature | -40 °C ... +70 °C |
| Housing Diameter | 18 mm |
| Property | Value |
| EMC Immunity | EN 60947-5-2 |
| EMC Emission | EN 60947-5-2 |
| Shock Resistance | IEC 60068-2-27 |
| Vibration Resistance | IEC 60068-2-6 |
| Approval (US) | cULus Listed |
| Approval (EU) | CE Conformity |
